Figure Window

When Shade3D starts, a new, empty scene is displayed in the Figure Window.

The Figure Window is essential for everything you do in Shade3D, and always remains open for currently open scenes.

You can have multiple scene files open simultaneously. Open files are shown via tabs at the top of the Figure Window. Click a tab to switch between open scenes.
